Trucks

ILMCV Trucks
TATA LPT 1109G
11449 Kg
GVW
62 kW (85HP) @ 2500 r/min
Power
3.8L NG SGI CNG
Engine
11449 Kgs
Deck Length
Enquire Now Contact Dealer
Brochure

TATA LPT 1109g

Engine
3.8 L NG SGI CNG
Speed
Torque
285 NM @ 1200 - 1600 rpm
powerfhouse
Fuel Tank
486 L & 576 L
Tyres
8.25R16 - 16 PR (Low CRR)
warranty
Warranty
3 Year | 300000 km
application
Applications
Cements Building Construction, Parcel & Courier E-commerce, Pharma, Fruits & Vegetable, FMCG, LPG Cylinder, Food Grains, Industrial Goods, Containers & Reefers, White goods

Superior TCO

  • Auto Shut off valve
  • High-pressure filter
  • Refueling interlock device
  • Electronic Viscous fan
  • Swagelok fittings
  • Reverse parking Buzzer
  • Gear Shift Advisor (GSA)
  • Improved Air Braking system

  • Higher torque available at lower RPM
  • Efficient engines for improved mileage
  • Dual FE Mode
  • Cruise control
  • OBD2, FOTA for advanced diagnostics
  • Advanced electronic control systems

  • Fleet Edge Telematics System
  • Advanced telematics features
  • Infotainment system with Fast USB charger
  • Steering mounted controls
  • 4G Enable Fleet Edge Telematics system
  • Infotainment system

  • Improved chassis thickness
  • Reduction in clutching and Gear shifting efforts
  • Improved suspension strength
  • Higher Ground Clearance
  • Enhanced Gradeability
  • PTO Provision
GVW / GCW (Kgs) 11449 Kg
Warranty 3 years or 300000 km, Whichever is earlier*
Brake Type Air Brake
Telematics Yes
Front Suspension Semi-Elliptical Leaf Springs with parabolic auxiliary
Rear Suspension Semi-Elliptical Leaf Springs with parabolic auxiliary
Rear Tyre 8.25R16-16PR
Front Tyre 8.25R16-16PR
No. of Wheels 6
Overall Length (mm) 8120 mm
Overall Height (mm) 2940 mm
Overall Width (mm) 2255 mm
Wheelbase (mm) 4530 mm
Max Power 85 PS @2500 rpm
Load Body Dimension L-6167, W- 2117, H- 1835
Load Body Type CBC
Load Body Length 6167 mm
Gearbox G550
Clutch Type Single plate dry friction type hydraulic assisted
Fuel Type CNG
Fuel Tank Capacity (Litres) 486 Ltr
Gradeability (%) 21.0
Engine Cylinders 4 Cylinders
Engine Type 3.8 SGI NA BS6 Engine
Emission Norms BS6 PH-2
Max Torque 285 NM @ 1200 - 1600 rpm
